High-Efficiency 8 Axis CNC Pipe and Square Tube Plasma Cutter for 245mm-800mm Tubes
Discover our CNC pipe cutter designed for cutting round pipes, square tubes, channel steel, and custom shapes. With a cutting diameter of 245mm to 800mm, length to 12000m, this rotary plasma cutter delivers high efficiency and precision for various industrial applications.
Professional CNC Pipe and Rotary Plasma Cutter for Round, Square, and Custom Steel Tubes
Model: LT3212-8PT(LT4212-8PT,LT5012-8PT,LT6012-8LT,LT8012-8LT)
Working area: 50-320mm (50-420mm,50-500mm,50-600mm,50-800mm as options)*12000mm
Support Plasma Power: LGK/Hypertherm 160A, LGK200A
Price Range: $500 000 – $950 000
Warranty time: 1 year for the whole machine
Delivery time: 15-20 workdays
Technical Support Time: Free Lifetime for All Clients
Machine Videos
Technical Parameter
| Model | LT3212-8PT(LT4212-8PT,LT5012-8PT,LT6012-8LT,LT8012-8LT) |
|---|---|
| Max Process Tube diameter | 50-320mm (50-420mm,50-500mm,50-600mm,50-800mm as options) |
| Max Process Tube Length | 12000mm |
| Plasma cutting tube thickness | 30mm |
| Round tube load | 3000KGS |
| A-axis | axis 360° free rotation, pipe rotation , |
| Y-axis | torch moves horizontally along the axial direction of the pipe, 430mm |
| B-axis | A=±60°,torch along the axis of the pipe axis, |
| C-axis | B=±45°,torch rotates along the radial plane of the pipe |
| Z axis | Maximum stroke 300MM,Torch vertical lifting axis |
| Plasma source | LGK/Hypertherm 160A / 200A |
| Flame cutting speed (optional) | 100-750mm/min |
| Plasma cutting speed | 1000-6000mm/min |
| Movement speed | 10-8000mm/min |
| Full power | 49KW/H |
| Voltage | 380V 50HZ |
| Machine weight | 4000kgs |
Machine Features
Unique Advantages: Steel and heavy tube welding heavy machine frame, can support more bigger tube materials, 8 axis styles of unique head can cut all most all the tube, also have bevel cutting functions
PC Controller: Adopt the Professional Industrial controller with screen, equipped with intelligent nesting software.
Unique Plasma Head: can rotate, forward, back, up and down to cut the different graphic and shape of tube, have perfect bevel cutting functions
Fiber Laser Power Supply: Equipped with LGK160A or 200A plasma power supply, also could adopt the better Hypertherm brand plasma source
Chuck System: Equipped with high-precision double chucks, the diameter could be 320-800mm as options
Transmission System: Hihg precision grinding rack add imported YYC perfect guild offer best working precision and longer service life, help machine process complex products on best accurancy.
Forward Support System: Used to support the heavy materials, also help to collect the cutting products
Distribution Box: Professional industrial distribution box, all the electrical parts, and control card.etc be installed well, perfect connect design let all the parts work well together, dust proofing is great, and can also Protect against electromagnetic interference.
Related Machine Pictures
Applicable Industry
With superior cutting processes and results, our types of equipment, the plasma tube cutter, is widely used in many different industries, such as the Advertising Industry, Automobile Manufacture Industry, Gym Equipment Industry, Machine Manufacturing Industry, Medical Equipment Industry, Sanitary Tools Industry, Sheet Metal Cutting Industry, Steel Structure Industry, Steel-Wood Furniture Industry, Tower Industry, and many other areas that required metal cutting solutions.
Aerospace Industry
New Energy Industry
Machine Manufacturing Industry
Elevator Industry
Gym Equipment Industry
Steel-Wood Furniture Industry
Sanitary Tools Industry
Medical Equipment Industry
Automobile Manufacture Industry
Handicraft Industry
